F-350, F-500 & F-650

EMSCO COMPATIBLE

Item

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
*Not shown

AMP Part No.
A-6318-0151-00

A-7507-2207-00
A-7601-0630-17
A-7507-3402-00
A-7601-0630-26
A-7507-3407-00
A-7601-0630-26
A-6318-0148-00
A-6318-0177-00
A-6318-0153-00
A-7602-2200-34
A-6318-0158-00
A-6318-0130-00
A-6318-0157-00
A-6310-0084-00
A-7501-0051-00*
A-6310-0133-00
A-6397-0602-00
A-6310-0016-01
A-7602-1600-23
A-7602-1600-33
A-6318-0155-00*

Description
Fluid Module, Studded (Incluye Items 2–7)
Fluid Module, Only
Stud – Frame
Nut – Frame
Stud – Threaded Ring
Nut – Threaded Ring
Stud – Discharge Manifold
Nut – Discharge Manifold
Liner Cage
Lower Valve Guide with Bushing
Locking Clip
Gasket – Liner
Cylinder Head Plug
Threaded Ring
Cylinder Head
Gasket – Valve Pot Cover
Retainer Bolt
Retainer Plate
Upper Valve Guide
Valve Pot Cover
Gasket – Discharge Manifold
Gasket – Suction Manifold
Lower Valve Guide Bushing

Qty. per Pump
(3)
3
18
18
36
36
12
12
3
3
3
6
3
3
3
3
12
3
3
3
3
3
3

OEM Part No.
6318-0151-00

7507-2207-00
7601-0630-17
7507-3402-00
7601-0630-26
7507-3407-00
7601-0630-26
6318-0148-00
6318-0177-00
6318-0153-00
7602-2200-34
6318-0158-00
6318-0130-00
6318-0157-00
6310-0084-00
7501-0051-00*
6310-0133-00
6397-0602-00
6310-0016-01
7602-1600-23
7602-1600-33
6318-0155-00*

High-pressure mud pump fluid end designed for triplex pump systems and oilfield drilling applications, compatible with a wide range of industry models including NOV F-1000, NOV FD-1600, NOV 12-P-160, NOV 14-P-220, Gardner Denver PZ-1600, PZ-9 and PZ-8, Cameron CMP-1600 and CMP-2200, Drillmec 12T1600 and 14T2200, BOMCO F-1600 and F-1600HL, Continental Emsco FC-2200, Weatherford MP-10 and MP-16, Honghua HHF-1600, Oilwell A-1700-PT, and American Mud Pumps AMP-2200L and AMP-1600L. This fluid end assembly includes an API-compatible fluid end module and fluid end block engineered for continuous duty in harsh environments. The design supports fluid end valves and seats, durable mud pump liners, a fluid end discharge flange and suction manifold, providing rugged performance, premium fluid end parts, and long-lasting fluid end components for demanding drilling rigs. This American-made fluid end is suitable for high-pressure offshore drilling, best-in-class oilfield rigs, and OEM or aftermarket

Descargo de responsabilidad:
American Mud Pumps es un proveedor independiente de componentes y extremos de fluidos para el mercado de repuestos. Los productos que se muestran están fabricados para ser 100 % intercambiables con piezas originales de marcas como National, LEWCO, EMSCO, Gardner Denver, Ideco y otras. Todas las referencias a nombres, marcas comerciales, números de pieza o modelos de fabricantes de equipos originales (OEM) se utilizan únicamente con fines de identificación y compatibilidad. American Mud Pumps no está afiliada, patrocinada ni avalada por los respectivos fabricantes de equipos originales.
